An ISO 9001:2008 Certified Company, Metline Industries (Steel Plates, Sheets and Coil Division) is a leading stockholder, supplier and exporter of ASTM A240 317L Stainless Steel Coils, Sheets and Plates in India and Worldwide. ASTM A240 317L Stainless Steel Coils can be cut to your specifications and supplied with complete set of mill test reports. Custom length and width up to 2000 mm can be made available in case of stainless steel 317L sheets and coils. Exports is Our Specialty!
317L is molybdenum bearing austenitic stainless steel similar to 316, but with higher molybdenum alloy content. It is also known as UNS S31700, and is primarily comprised of 18% to 20% chromium and 11% to 15% nickel.
317L offers higher creep, stress-to-rupture, and tensile strength at elevated temperatures than conventional stainless steels. It is a low carbon grade which provides resistance to sensitization during welding and other thermal processes.
Metline Industries is a leading stockholder and distributor of stainless steel 317L coils, 317L sheet, and SS 317L plates in India.
317L has excellent corrosion resistance and is used mainly in high acidic chloride media, such as those encountered in pulp and paper mills.
317L pipes, tubes, bar, fittings, plates and sheets are primarily used in manufacturing flue gas desulfurization systems, textile equipment, chemical and petro-chemical processing equipment, pulp and paper plants, food processing equipment and textile equipment. We specialize in supply of 317L sheets, plates. seamless pipes and tubes, along with equivalent fittings for manufacture of heat exchangers, piping systems, tanks and pressure vessels.
Brand: Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin
Manufacturer: POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, SAIL, VDM, Nippon Metal
Size Range: 2.0 to 50 mm in width of 1000mm, 1250mm, 1500mm, 2000mm
ASTM A240: Standard Specification for Chromium and Chromium-Nickel Stainless Steel Plate, Sheet, and Strip for Pressure Vessels and for General Applications
The ASTM A240 specification covers chromium, chromium-nickel, and chromium-manganese-nickel stainless steel plate, sheet, and strip for pressure vessels and for general applications. The steel shall conform to the requirements as to chemical composition specified. The material shall conform to the mechanical properties specified.
| STAINLESS STEEL | TRADENAME | UNS NO. | WERKSTOFF NO. | DENSITY (G/CM3) |
| 317L | 317L Stainless | S31703 | 1.4438 | 8 |
Stainless Steel 317L Chemical Composition, %
| C | MN | SI | P | S | CR | NI | MO | N |
| 0.03 max. | 2.00 max. | 0.75 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0-15.0 | 3.0 – 4.0 | 0.1 |
Physical & Mechanical Properties of Stainless Steel 317L
| | 317L |
| Density | 7.92 |
| Melting Range,℃ | 1450 |
| Elongation % | 40 |
| Tensile Strength (Mpa) | 515 |
| Yield Strength (Mpa) | 205 |
| Hardness (Brinell) | 217 |
